Specification: Charging Voltage: 6*4.2VCharging Currect: 15ACharging Overcurrent Protection Value: 26ABalance Enable Voltage: 4.125VBattery Balance Current: 25 ± 5mAOvercharge Detection Voltage: 4.25 ± 0.05VOvercharge Release Voltage: 4.15 ± 0.05VDischarge Current: 30ADischarge Overcurrent Protection Value: 66AOver-discharge Detection Voltage: 2.8 ± 0.05VOver-discharge Release Voltage: 3.0 + 0.05VOver-discharge Detection Delay: 1Sshort Circuit Detection Delay: 200-500 μS (The actual results are subject to the customer's return and inspection)Working Temperature Range: -30°C~70°CStorage Temperature Range: -40°C~125°CTemperature Protection: Charging: -10°C~50°C, Discharging: -30°C~70°C (can be customized)Sleep Current (Battery Over-discharge): 10μA

Read more less

MAXKGO-SS BMS is a full-featured battery protection board for electric vehicles, light electric vehicles, and electric skateboards. It is an intelligent mini BMS that integrates charging protection, discharge protection, overcurrent protection, temperature protection, and balance protection.（The factory default setting is 12S. If you need to change it, please modify it yourself.） Firmware & software repositories are available click here： MAXKGO Tutorial on MAXKGO BMS settings with VESC Applicable battery voltage Recommended Battery: 6S-12S Operating Voltage Range per Cell: 2V-5V Charging Charging Voltage: 24V-52V Charging Current: ≤50A Maximum Supported Charging Voltage: 60V Minimum Supported Charging Voltage: 14V Overcharge Protection Overcharge Detection Voltage: 2V-5V Overcharge Protection Delay: ≥4ms Overcharge Release Voltage: 2V-5V Discharging Discharge Current: ≤200A Overcurrent Protection for Discharge: ≤200A Discharge Voltage: 24V-52V Overdischarge Protection Overdischarge Detection Voltage: 0-5V Overdischarge Release Voltage: 0-5V Overcurrent Protection Overcurrent Protection Delay for Discharge: ≥4ms Overcurrent Protection Release Condition: Load Disconnect Short Circuit Protection Short Circuit Protection Condition: External Load Short Circuit Short Circuit Detection Delay: 320µs Short Circuit Protection Release Condition: Load Disconnect Balancing Current: 86mA @4.2V Temperature Protection Temperature Protection: -20℃ to +120℃ Operating Temperature Operating Temperature Range: -20℃ to +80℃ Storage Temperature Storage Temperature Range: -20℃ to +100℃ Self-Consumption Operating Current: ≤40mA Sleep Current: ≤100µA BMS  Details Includes: Overcharge Protection, Overdischarge Protection, Overcurrent Protection, Temperature Protection, Battery Capacity Detection, Battery Internal Resistance Detection, Thermal Management, Balancing Function Balancing Method: Active Balancing and Passive Balancing Short Circuit Protection: External Load Short Circuit Short Circuit Protection Recovery: Load Disconnect Battery Support: Supports nearly all lithium batteries including Li-ion, Li-polymer, LiFePO4, etc. BMS Edge Compact layout, ultra-mini size. Automotive-grade monitoring and balancing IC with independent power supply for enhanced reliability. Voltage detection of load, charger, and battery pack. Bidirectional current monitoring. SOC based on Coulomb counting. Humidity sensor and circuit board temperature monitoring. Charger circuit detection capability. Integrated pre-charge circuit. Features power button, USB-Type C, UART, I2C, and isolated CAN bus interfaces. Onboard efficient 3.3V regulator powered by the main battery pack. Uses high-current capacity automotive-grade screw connectors for main power connection. Includes buzzer and LED display. Aluminum alloy shell for improved heat dissipation. Automotive-grade locking mechanism with reverse interlock to ensure secure connections. Compatible with MAXKGO-BMS-TOOL and ENNOID-BMS-TOOL. BMS Safety Features Configurable under-temperature and over-temperature cutoff for charging and discharging. Configurable under/over battery voltage cutoff. Configurable overcurrent cutoff. Configurable minimum pre-charge value. High-side load and charger disconnect. Transient voltage suppression on all inputs. Secondary fuse on all balance channels, USB ports, and power supplies.   Package include： 1* PCB board 1* HY2.0 single-end 10-pin wire 1* HY2.0 single-end 13-pin wire 2* GH1.25 single-end 5-pin wire 1* GH1.25-5P to DuPont wire adapter 1* USB cable, Type-C data cable 1* 2.0MM jumper cap 1* 1.3-inch OLED display LCD module 1* 12MM 3-6V push-button switch 4* M5*8 stainless steel round head screws 2* M5*12 stainless steel round head screws 2* M5 copper nuts 6* M5 purple copper washers 6* 90-degree angled wire terminals T90-6/5 (purple copper) 2* fuses Video:

Read more less

Firmware & software repositories are available click here： MAXKGO MAXKGO BMS User Manual:MAXKGO Remark: Only Support 6S-28S 12A Smart Only Charge BMS and 6S-24S 150A Smart BMS Maxkgo-BMS Privacy Policy (1)Maxkgo-BMS User Protocol (1) Package Included:  1* MKBMS 6S-24S Smart Bluetooch VESC BMS Board(With aluminum shell) 1* Bluetooth module 1* UART module 1* 1.3 inch OLED display LCD screen module 1* 12MM 3-6V key switch 1* GH1.5 single head 5P line 1* GH1.25-5P to Dupont line 1* PH2.0 single head 13P line 1* PH2.0 single head 12P line 1* PH2.0 single head 8P line Operation Notes: Please ensure the correctness of the wiring sequence, from B0-B12, B13-B24, the voltage increases from low to high in sequence. 1. This BMS is compatible with battery packs up to 24s, which is over 102V when fully charged. Electric shocks from high voltage may cause serious injury.Please pay attention to safety when using.

Read more less

Firmware & software repositories are available click here： MAXKGO MAXKGO BMS User Manual:MAXKGO Maxkgo-BMS Privacy Policy (1)Maxkgo-BMS User Protocol (1) Remark:Only Support 6S-28S 12A Smart Only Charge BMS and 6S-24S 150A Smart BMS Specs: ●Type:Smart Charge only ●Cell Chemistry: Li-ion/LiFePO4 ●Number of Battery Strings: 6S-28S ●Charge Current: 12A ●Single cell voltage Sdetection range: 2v-5v,error value:±2mV ●Balance: 28mA@4.2V,Passive balance ●connector:XT30/XT60 ●Short Circuit Protection:Support. ●Bluetooth Function:with Bluetooth ,Support for Android  ●Temperature detection:-30～125℃. ●Voltage support range: 15V-118V ●Abs. Max battery voltage: 120V ●Shutdown Consumption: <80uA ●Quantity of Temperature Detection: 4 Pcs(NTC) ●SoC estimation accuracy:Error:8%(operating conditions). ●Operating power consumption:<40mA(UART/CAN). ●Standby power consumption:<100uA. ●Charge protection Temp: 0°C~100°C ●Charge Temp Reset: 0°C~100°C ●Recommended Working Temp:-20°C~+75°C ●Size: 112.17*33.7*12.8mm Notice:The Each S voltage can only be set to a maximum of 4.2V for 28S battery pack Package Included: 1* MKBMS 6S-28S 12A Smart Only Charge Board(With aluminum shell) 1* Bluetooth module 1* UART module 1* 1.3 inch OLED display LCD screen module 1* 12MM 3-6V key switch 1* GH1.5 single head 5P line 1* GH1.25-5P to Dupont line 1* PH2.0 single head 15P line 1* PH2.0 single head 14P line 1* PH2.0 single head 8P line Wiring Diagram Operation Notes: Please ensure the correctness of the wiring sequence, from B0-B15, B16-B28, the voltage increases from low to high in sequence. This BMS is compatible with battery packs up to 28s, which is over 118V when fully charged. Electric shocks from high voltage may cause serious injury.Please pay attention to safety when using. This device can only be used for charging to reduce the risk of overcharging, but cannot prevent Discharge over-current, short circuit, and over-discharge.

Read more less

Product Description-- Charging current: <60A Discharge current: < 150A Internal resistance: ≤15mΩ   Charging voltage: The number of Li-ion battery in series connection X 4.2VWiring : same port or different ports（When using the charging and discharging same port, disconnect the p-）   Overcharge protection—— Detection voltage: 4.25±0.025V Detection delay: 1000±500MS Release voltage: 4.15±0.05V   Over-discharge voltage protection—— Detection voltage: 2.75±0.1V Detection delay: 1000±500MS Release voltage: 3.0±0.1V   Balanced voltage—— Detection voltage: 4.15±0.025V Detection delay: 100±50MS Balance current: 42±5MA   Over discharge current protection—— Detection voltage: 50±15MV Detection delay: 1000±500MS Current protection: 300±50A 450±50A 600±60A   Short circuit protection-- Trigger condition: external short circuit Detection delay: 300us Release condition: disconnect the load   Temperature control protection—— Charge and discharge over-temperature protection: 55℃ Charge and discharge high temperature release temperature: 75℃ Release condition:During normal working temperature          Self-consumption—— Working power consumption: <35UA Over-discharge power consumption(Sleeping State): <10UA Operating temperature range: -30°~+80°C   Product Features-- Overcharge protection Over discharge protection Over current protection Balanced protection Temperature control protection Applicable for 8-14S battery   Size:121*50*12.8mm Net weight:244g Weight: 331.5g   Package: 1* PCBA board 1*HY2.0 single head 15P line   Wiring diagram

Read more less

Specifications-- 1. Input voltage: 9V-90V The minimum voltage difference between the input voltage and the output voltage is 4V  (when the output is 5V, the input is DC9V-90V, and when the output is 12V, the input voltage is DC16V-90V. 2. Output voltage: 12V/5V 3. Maximum output current: 3A (that is, the constant current value is 3A, when the customized voltage is higher than 12V, the output current is less than 3A, the power is not recommended to exceed 30W, 12V and 5V can reach 3A.) 4. Typical operating frequency: 140KHz 5. High efficiency: up to 95% (the smaller the pressure difference, the higher the efficiency) 6. Working temperature: industrial grade (-40℃ to +85℃) 7. Module volume: 42*30*17mm   Product Advantages-- Frequency reduction at light load to improve light load efficiency. Small standby current. Built-in over-temperature, over-current, output short-circuit protection. Built-in soft start. Constant voltage and constant current output.   Instructions: First connect the connection line between the module and the power supply, and then power on. (If the input terminal is connected with electricity, it is prone to sparking, especially when the input power supply voltage is high, the pad of the module may even be burnt). After selecting a suitable power supply, use a multimeter or voltmeter to measure whether the output voltage of the module is consistent with the voltage required by the device. Connect electrical equipment or (load) to the output of the module. Package List: 1x DC-DC STEP-DOWN POWER SUPPLY MODULE

Read more less

Specification MAXKGO DCDC 450V to 12V Step-down Power Supply Module is a high-voltage DC-DC converter from 450V to 12V and can provide a DC current of 4.2A. The input voltage can support the range of 150V-450V.The out voltage is equipped with a fine adjustment that be adjusted with a range of 11.8V-12.2V DC. The converter has good stability and reliability and is widely used in various occasions that require high-voltage conversion to low-voltage. Feature Output characteristics Input voltage：100-450V DC Output voltage：12V/4.2A Output voltage accuracy：±1% Ioading effect：10%~100%Ionom  △Voutnom≤±0.2% Source effect ：Vinmin~Vinmax △Voutnom≤±0.2% Ripple：100mV Conversion efficiency：80% （Typical value） Temperature Coefficient：≤±0.02%/℃（Maximum） Security features Isolation voltage：Vin~Vout   Vin~FG   Vout~FG   All are 500vdc/min Insulation resistance：≥100MΩ Protective function：Short circuit protection（self-recovery） Environmental characteristics Working temperature：-25 ~ +85℃ Storage temperature：-40 ~ +105℃ Relative humidity：10RH ~ 90RH Implementation standards Electromagnetic Compatibility:IEC100、EN61000 Safety：UL1950、IEC950  Features High power density, small size Multiple protection function Enhanced electromagnetic compatibility design, can work in strong electromagnetic environment Integrated potting process, anti-corrosion, moisture-proof and shock-proof Good thermal conductivity and reliability Application MAXKGO Master-slave BMS Energy storage Photovoltaic New energy vehicles Widely used in various occasions requiring DCDC conversion Shipping list 1X    MAXKGO DC-DC 450V to 12V Converter 1X    GH2.0 single head 2P cable（With buckle） 1X   power cable Operational matters Please ensure the correctness of the wiring sequence when wiring. The input voltage will reach a maximum of 450V. There is a risk of electric shock, so please pay attention to protection.

Read more less

Specifications :  Firmware: 5.2 (supporting firmware upgrade)  Continuous current: 150A; instantaneous current: 200A (values depend on the mounting and ambient temperature around the device!)  Voltage: 14V-60V ( Cells: 4-13S; safe for 4S to 12S, voltage spikes may not exceed 60V! )  BEC: 5V@1.5A; ERPM: 150000  Supported sensors: Sensorless Supported Modes: BLDC, FOC (sinusoidal)  Control Interface Ports: USB UART  Input Set Support: PPM, ADC, NRF, UART  Regenerative capacity: Yes Programmable: Yes   Power Wire: 8AWG 1200mm / Motor Wire: 8AWG 170mm   Size: 103.5x67.6x27.5mm(Including aluminum case)  Features:  1.Fully sealed with IP68 water-proof rate.  VESC ESC: based on vesc6, programmable via VESC_TOOL and support real-time data read.  2.6-layer 3oz special PCB plate with good heat dissipation, support rated current 150Amps. 3.Adopting CPU STM32F405 with the structure of ARM Cortex-M4 allows CPU clock speed.  4.Support three control modes: Current / Dutycycle / Speed.  5.Multiple protection functions: low voltage protection, high voltage protection, over-current protection, temperature abnormally protection, mosfets over-temperature protection over 80 ℃.  6.Compact size with high efficiency: 103.5x67.6x27.5mm.  Wiring Diagram:

Read more less

MKBMS is based on the modular BMS of LTC6811, and is connected to one or more slave boards and integrated boards of different sizes through the ISOSPI interface.  LTC6211 12S Slave BMS Features —— 1. Aluminum alloy PCB, better heat dissipation effect. 2. Compatible with MKBMS and ENNOID BMS. 3. from 5-12 series-connected battery cells per board. 4. 1+4 temperature sensors per slave. 5. Self-powered by the monitored cells. 6. Ultra-low power consumption, sleep mode = 6uA. 7.It can be connected to multiple slave boards to form an integrated board through the ISOSPI interface 8.Daisychain Master ISOSPI communication 9.1.2mV accuracy, -40 to 120C operation 10.33 ohm balance resistors (0.125A capacity) on all channels 11.Scalable & isolated 1000VDC+ 12.Molex SL horizontal connectors for balance & temperature. (Comes with male, female + crimps) Note:　The first temperature channel is used by slave board itself. The following 4 temperature sensors are not in the package lists,  but means an interface to connect 4 temp sensors at most.  Shipping List: 1X   PCBA board LTC6811-12W-AL V1.2 slave board 2X   GH1.25 double head 2P same direction line 1X   HY2.0 single head 5P line 1X   HY2.0 single head 13P line 4X   Nylon column 4X   Nylon nut

Read more less

MKBMS is based on the modular BMS of LTC6812, and is connected to one or more slave boards and integrated boards of different sizes through the ISOSPI interface.   MKBMS Function —— Overcharge protection: Yes Over discharge protection: Yes Temperature protection: Yes Thermal management: Yes Balance function: Yes Balance method: passive balance  Battery pack capacity detection: Yes Battery internal resistance detection: Yes Support battery: support almost all lithium batteries such as lithium ion battery, lithium polymer battery, lithium phosphate battery, etc.   LTC6212 15S Slave Board Features —— 1. Aluminum alloy PCB, better heat dissipation effect. 2. Compatible with MKBMS and ENNOID BMS. 3. From 5-15 series-connected battery cells per board. 4. 1+8 temperature sensors per slave. 5. Self-powered by the monitored cells. 6.Ultra-low power consumption, sleep mode=6uA. 7. It can be connected to multiple slave boards to form an integrated board through the ISOSPI interface 8. Daisychain Master / Slave ISOSPI communication 9. 1.2mV accuracy, -40 to 120C operation 10. 33 ohm balance resistors (0.125A capacity) on all channels 11. Scalable & isolated 1000VDC+ 12. Molex SL horizontal connectors for balance & temperature. (Comes with male, female + crimps) *The first temperature channel is used by slave board itself. The following 8 temperature sensors are not in the package lists but means an interface to connect 8 temp sensors at most.   MKBMS Functions: Current and voltage protection: protect the battery pack from overcharge and over discharge, thereby extending the cycle life. Battery health monitoring: monitor the internal resistance of a single battery and the monitoring capacity of the battery pack. Thermal management: Overheating and under-temperature protection. Support batteries: Li-Ion, Li-Polymer, Li-Phosphate Intelligent battery balance: passive balance  Field programmable Current limit calculation Fully programmable CANBUS interface, programmable structure of all CAN messages Drift state of charge Reliability, speed and accuracy Integration with other devices Multiple BMS units connected in series Current sensor support Isolation from fault detection Automotive grade design, automotive grade locking connector Software for data logging and programming   MKBMS can be divided into three aspects: automobile, industry, consumption: Electric vehicles Electric patrol car Scenic sightseeing car Handling robots Automatic forklift Electric two-wheeler AGV forklift Sightseeing car Electric tricycle Electric mobility vehicles RV Solar street light Outdoor energy storage Home energy storage equipment Robotand etc.   Shipping List:  LTC6812-15S  Slave Board Package—— 1X   PCBA board LTC6812-15S slave board 1X  GH1.25 double head 2P red-black line (for master board)   1X  GH1.25 double head 2P black-white line (for slave board) 2X   HY2.0 single head 8P line 1X   HY2.0 single head 16P line 4X   Nylon column 4X   Nylon nut   Specification Size：100 x 60mm Net Weight：31.8g Package Size：140 x110 x 50 mm Package Weight：120g Outer Package Size：160*120*75mm Outer Package Weight ：240g

Read more less

MKBMS is developed based on the open source materials of DieBieMS and ENNOID BMS. Currently MKBMS is compatible with ENNOID firmware. Here, a special thanks to the developers of open source BMS materials. Maybe you need more MKBMS options: https://bit.ly/3xR2DJS MKBMS Slave Board Features: MKBMS slave board is made of aluminum base plate, which has better heat dissipation effect. Scalable & isolated 1000VDC+ Compatible with MKBMS Master boards From 5 to 18 series-connected battery cells per board Daisychain Master/Slave ISOSPI communication Parameters fully programmable through an easy to use graphical user interface 33 ohm balance resistors (0.125A capacity) on all channels Self powered by monitored cells 1.2mV accuracy, -40 to 120C operation Extra low power consumption (Sleep mode = 6uA) Molex SL horizontal connectors for balance & temperature. (Comes with male, female + crimps)       Variant:            LTC6813 : Up to 18 cells voltage monitoring & 1+8 temperature sensors* per slave      *The first temperature channel is used by slave board itself. The following 4 or 8 temperature sensors are not in the package lists but means an interface to connect 8 temp sensors at most.    MKBMS can be roughly divided into three aspects: automobile, industry, and consumption: 1.  Electric vehicles;2.  Electric patrol car;3.  Scenic sightseeing car;4.  Handling robots;5.  Automatic forklift;6.  Electric bicycles;7.  Electric skateboard;8.  Electric tools;9.  Consumer robots, etc.   LTC6813-18S  Package 1X PCBA board LTC6813-18S V1.4 slave board 1X  GH1.25 double head 2P red-black line (for master board)   1X  GH1.25 double head 2P black-white line (for slave board) 1X HY2.0 single head 6P line 1X HY2.0 single head 13P line 1X HY2.0 single head 16P line 4X nylon column 4X nylon nut

Read more less

Click it MINI V6.8 Specifications :  Firmware:  vesc_tool_3.00 5.2 (supporting firmware upgrade) Continuous current: 100A; instantaneous current: 150A (values depend on the mounting and ambient temperature around the device!) Voltage: 14V-60V(Cells: 4-13S; safe for 4S-12S, voltage spikes may not exceed 60V! )  BEC: 5V@1.5A; ERPM: 150000 Support Hall Sensor: No, Sensorless Supported Modes: BLDC, FOC (sinusoidal) Control Interface Ports: USB, CAN, UART, IIC Input Set Support: PPM, ADC, NRF, UART Regenerative capacity: Yes Programmable: Yes Motor wire: 10AWG; Power cable: 8AWG Size: 64x43.5x34.7mm(Including heatsink) Features: Based on vesc6, programmable via VESC_TOOL and support real-time data read. Adopting CPU STM32F405 with the structure of ARM Cortex-M4 allows CPU clock speed.  Support three control modes: Current / Dutycycle / Speed. Protection functions: low voltage protection, high voltage protection, over-current protection, temperature abnormally protection, mosfets over-temperature protection. Support the function of balancing car by connecting the IMU module through the IIC interface; support inertial measurement unit modules such as MPU9250, MPU9150, MPU6050, LSM6DS3, BMI160 Wiring diagram: MINI V6.8 Plus Specifications :  Firmware: 5.2 (supporting firmware upgrade) Continuous current: 150A; instantaneous current: 200A (values depend on the mounting and ambient temperature around the device!) Voltage: 14V-60V ( Cells: 4-13S; safe for 4S to 12S, voltage spikes may not exceed 60V! ) BEC: 5V@1.5A; ERPM: 150000 Supported sensors: ABI, HALL,AS5047,AS5048A Supported Modes: BLDC, FOC (sinusoidal) Control Interface Ports: USB, CAN, UART, IIC Input Set Support: PPM, ADC, NRF, UART Regenerative capacity: Yes Programmable: Yes Power Wire: 8.0mm bullets female X 2pcs Motor Wire: 8.0mm bullets female X 3pcs Size: 92.7x68x31.5mm(Including aluminum case) Features: 1) Based on vesc6, programmable via VESC_TOOL and support real-time data read. 2) Adopting CPU STM32F405 with the structure of ARM Cortex-M4 allows CPU clock speed. 3) Support four control modes: Current / Dutycycle / Speed 4) Protection functions: low voltage protection, high voltage protection, over-current protection, temperature abnormally protection, mosfets over-temperature protection. 5) Support the function of balancing car by connecting the IMU module through the IIC interface; support inertial measurement unit modules such as MPU9250, MPU9150, MPU6050, LSM6DS3, BMI160 Wiring diagram:
