Remark:Only Support 6S-28S 12A Smart Only Charge BMS and 6S-24S 150A Smart BMS
-
New Arrival 5% Discount Code:DQJ111
Specs:
●Type:Smart BMS Board
●Cell Chemistry: Li-ion/LiFePO4
●Number of Battery Strings: 6S-24S
●Charge Current: 30A
●Discharge current:150A
●Single cell voltage Sdetection range: 2v-5v,error value:±2mV
●Balance: 28mA@4.2V,Passive balance
●connector:Wiring Terminal
●Short Circuit Protection:Support.
●Bluetooth Function:with Bluetooth,Support for Android
●Temperature detection:-30~125℃.
●Voltage support range: 15V-102V
●Abs. Max battery voltage: 120V
●Shutdown Consumption: <80uA
●Quantity of Temperature Detection: 10 Pcs(NTC)
●SoC estimation accuracy:Error:8%(operating conditions).
●Operating power consumption:<40mA(UART/CAN).
●Standby power consumption:<100uA.
●Charge protection Temp: 0°C~100°C
●Charge Temp Reset: 0°C~100°C
●Recommended Working Temp:-20°C~+75°C
●Size: 143.3*64.2*19.4mm
Package Included:
1* MKBMS 6S-24S Smart Bluetooch VESC BMS Board(With aluminum shell)
1* Bluetooth module
1* UART module
1* 1.3 inch OLED display LCD screen module
1* 12MM 3-6V key switch
1* GH1.5 single head 5P line
1* GH1.25-5P to Dupont line
1* PH2.0 single head 13P line
1* PH2.0 single head 12P line
1* PH2.0 single head 8P line
Operation Notes:
- Please ensure the correctness of the wiring sequence, from B0-B12, B13-B24, the voltage increases from low to high in sequence.
-
1. This BMS is compatible with battery packs up to 24s, which is over 102V when fully charged. Electric shocks from high voltage may cause serious injury.Please pay attention to safety when using.
