Specifications:
Firmware: V1.6 or above (firmware update via Flipsky ESC Tool supported)
Voltage: 14-110V(safe for 4-26S)
Continuous current: 100A (Values depend on the mounting, ambient temperature and air/water circulation
around the device!)
Peak Current: 250A
Communication Ports: USB, CAN, UART, PPM, ADC, PAS
Input Signals Support: PPM, ADC, PAS (Cadence Input Signal), UART (compatible with all Flipsky VX
Series remotes)
BEC: 5V@1A
Programmable Tool: Flipsky ESC TOOL
PWM Frequency Control: YES
Multiple Speed Gear Limit Control: YES (UART&ADC)
Regenerative Capacity: YES
Integrated Self-locking Switch: 16mm Red Button
Motor/power wire size: 10 AWG
Size: L117.7*W62.4*H21.7mm (Including Alu. Case)
Feature:
Adopting ARM Cortex-M4 structure with the max 240MHz , improves PWM switching frequency
and the motor RPM.
Programmable via Flipsky ESC Tool to be compatible with multi-types of motor, different battery voltages
and many control ways.
Programmable via Flipsky VX4Pro remote (remote firmware version: VX4 Pro_V1.2 or above).
Supporting motor FOC with low working noise and smooth starting.
Supporting real-time data and fault alerts.
Supporting adaptive variable PWM frequency control.
Supporting save / load configuration files via ESC Tool.
Supporting multiple speed levels: Level 1 (Low), Level 2 (Medium), Level 3 (High), Level 4 (PAS Only),
Level 5 (PAS Only).
Supporting sensor mode (HALL, ENCODER) and sensorless mode (IPDS, HFPI, OPEN).
Startup Modes Support: IPDS (sensorless), HFPI (sensorless), HALL (sensored), ENCODER (such as
ABI Encoder, AS5047 SPI, TLE5012 SPI, AS5600 IIC), OPEN (Sensorless Open-Loop Startup)
Traction Control: YES
Supporting control types: Current, Duty Cycle, Speed control, Position Control.
Supporting PAS cadence sensor.
Supporting emergency stop and shutdown.
Support safe power-on protection (in PPM&ADC control modes only).
Protection functions: low and high voltage protection, MOSFET over-temperature and over current
protection, battery overcharge and discharge protection, motor over-temperature protection.
Supporting multiple typed of motor temperature sensors such as NTC-10K-25℃ , NTC-10K-100℃ ,
PT1000, PTC-1K-100℃ , KTY and so on.
Application Fields:
Electric skateboard / Ebike / E-Scooter / Electric Motorc ycle / Robotics / FPV / RC Toys / Boat / Kayak etc.
Wiring diagram:
