ELRS 2.4G NANO Receiver - High Refresh Rate CRSF for FPV Racing Drones & Fixed-Wing

Beschreibung

ELRS 2.4G NANO Receiver Specifications

Product Overview
  • Origin: Mainland China
  • Brand: ELRS
  • Model: ELRS 2.4G NANO RX
  • Type: Receiver
  • Voltage: 5V
  • Color: Black
Technical Parameters
  • Name: ExpressLRS Receiver
  • Frequency: 2.4GHz
  • Chipset: SX1281 + ESP8285
  • Antenna: T-type (Dipole)
  • Output Power: 100mW
  • Input Voltage: 3.6V - 5.5V
  • Antenna Connector: IPEX1
  • Weight: 0.4g (Receiver only)
  • Dimensions: 11mm x 18mm
  • Firmware Version: 3.5.3
  • Channels: 16
  • Protocol: CRSF
Package Contents
  • 1 x Receiver
  • 1 x T-type Antenna
  • 2 x Heat Shrink Tubing
  • 1 x 4P Connection Cable
LED Status Indicators
  • Double Flash: Binding Mode
  • Slow Flash: No Transmitter Signal
  • Solid On: Signal Connected
  • Fast Flash: WiFi Update Mode
Binding & Update Instructions
  • Binding: Rapidly power the receiver on and off 3 times to enter Binding Mode. You have a 20-second window (indicated by the double flash) to complete the binding process.
  • WiFi Update: After the binding window expires, the receiver will automatically enter WiFi Update Mode.
