In order to meet more needs, MKBMS has launched another 4S-30S 20A Charge Only Board designed specifically for Onewheel/Ebike/Eskateboard/EUC.
This blog will explain in detail the specifications, functions, operations, etc. of this dedicated BMS for charging.



Features:

1. Compact charge only design
2. Cell balance indicator LEDs
3. Compatible with 4S-30S batteries
4. Designed to be ultra-compact and simple to use without any configuration required
5. Anodized aluminum heatsinkcase, stable performance.



Specifications:

Tpye	Charge Only
Cell Chemistry	Li-ion (3.7V nominal)
Series Count	4-30S
Charge Current	20A
Balance method	Passive balance
Balance Voltage	20-30mA@4.20V
Overcharge Voltage	4.25V
Overcharge Reset	4.19V
Overtemperature	60℃
Overtemperature Reset	40℃
Size	130*30*11mm
Net weight	30g



Operation Notes:

1. Please ensure the correctness of the wiring sequence, from B0-B15, B16-B30, the voltage increases from low to high in sequence.
2. This BMS is compatible with battery packs up to 30s, which is over 5V DC when fully charged. Electric shocks from high voltage may cause serious injury. Please pay attention to safety when using.
3. This device is designed to reduce the risk of charging and will not protect against overcurrent discharge, undervoltage, internal pack shorts, pack overtemperature.





Common Uses:

▪ One-wheeled electric skateboards

▪ Electric Skateboards

▪ Electric Scooters

▪ Electric Bikes

▪ EUC

Thank you for your patience in reading, see you in the next blog.
